| General information |
| Product type designation | SB 1223, DI 2x24 V DC/DQ 2x24 V DC |
| Supply voltage |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Input current |
| from backplane bus 5 V DC, typ. | 50 mA |
| output voltage / header |
| supply voltage of the transmitters / header |
| ● Supply current, max. | 4 mA; per channel |
| Power loss |
| Power loss, typ. | 1 W |
| Digital inputs |
| Number of digital inputs | 2; Current-sinking |
| ● in groups of | 1 |
| Input characteristic curve in accordance with IEC 61131, type 1 | Yes |
| Number of simultaneously controllable inputs |
| all mounting positions |
| — up to 40 °C, max. | 2 |
| Input voltage |
| ● Rated value (DC) | 24 V |
| ● for signal "0" | 0 to 5 V |
| ● for signal "1" | +15 to +30 V |
| Input current |
| ● for signal "0", max. (permissible quiescent current) | 1 mA |
| ● for signal "1", typ. | 7 mA |
| Input delay (for rated value of input voltage) |
| for standard inputs |
| — parameterizable | Yes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms and 12.8 ms, selectable in groups of four |
| — at "0" to "1", max. | 2 µs |
| — at "1" to "0", max. | 10 µs |
| for interrupt inputs |
| — parameterizable | Yes |
| for technological functions |
| — parameterizable | Yes |
| Cable length |
| ● shielded, max. | 50 m |
| Digital outputs |
| Number of digital outputs | 2; MOSFET, solid-state (current-sinking/current-sourcing) |
| ● in groups of | 1 |
| Short-circuit protection | No |
| Switching capacity of the outputs |
| ● with resistive load, max. | 0.5 A |
| ● on lamp load, max. | 5 W |
| Load resistance range |
| ● upper limit | 0.6 Ω |
| Output voltage |
| ● Rated value (DC) | 24 V |
| ● for signal "0", max. | 0.1 V; with 10 kOhm load |
| ● for signal "1", min. | 20 V |
| Output current |
| ● for signal "1" rated value | 0.5 A |
| ● for signal "1" permissible range, max. | 0.5 A |
| ● for signal "0" residual current, max. | 10 µA |
| Cable length |
| ● shielded, max. | 50 m |
| Interrupts/diagnostics/status information |
| Alarms | Yes |
| Diagnostics function | Yes |
| Diagnostics indication LED |
| ● for status of the inputs | Yes |
| ● for status of the outputs | Yes |
| Standards, approvals, certificates |
| CE mark | Yes |
| CSA approval | Yes |
| UL approval | Yes |
| cULus | Yes |
| FM approval | Yes |
| RCM (formerly C-TICK) | Yes |
| KC approval | Yes |
| Marine approval | Yes |
| Ambient conditions |
| Free fall |
| ● Fall height, max. | 0.3 m; five times, in product package |
| Ambient temperature during operation |
| ● min. | -20 °C |
| ● max. | 60 °C |
| ● horizontal installation, min. | -20 °C |
| ● horizontal installation, max. | 60 °C |
| ● vertical installation, min. | -20 °C |
| ● vertical installation, max. | 50 °C |
| Ambient temperature during storage/transportation |
| ● min. | -40 °C |
| ● max. | 70 °C |
| Air pressure acc. to IEC 60068-2-13 |
| ● Storage/transport, min. | 660 hPa |
| ● Storage/transport, max. | 1 080 hPa |
| Relative humidity |
| ● Operation at 25 ℃ without condensation, max. | 95 % |
| Mechanics/material |
| Enclosure material (front) |
|
| ● Plastic | Yes |
| Dimensions |
| Width | 38 mm |
| Height | 62 mm |
| Depth | 21 mm |
| Weights |
| Weight, approx. | 40 g |
